System type 系统类型⼆单元⼀路⾳箱

Frequency response(-5 dB standard) 频率响应 70Hz-18KHz

Power handling capacity (RMS/peak 10 ms) 功率60W/150W

Nominal impedance 标称阻抗4Ω

Sensitivity(1M/W) 灵敏度94dB

Max SPL 最⼤声压级100dB

Nominal dispersion angle(h x v) 覆射⻆度100°X100°

Components 单元配置低⾳2x4

Connections 连接⽅式 夹线

Suspension Point 吊挂点 4个M8螺丝吊挂点

Enclosure Material 箱体材质 12mm多层夹板

Surface treatment 表⾯处理 ⽔性点漆

Dimensions( H x W x D)箱体尺⼨260x125x145mm

Weight净重3kg
