System type 系统类型四单元⼀路⾳箱

Frequency response(-5 dB standard) 频率响应 70Hz-19kHz

Power handling capacity (RMS/peak 10 ms) 功率140W/280W

Nominal impedance 标称阻抗8Ω

Sensitivity(1M/W) 灵敏度95dB

Max SPL 最⼤声压级105dB

Nominal dispersion angle(h x v) 覆射⻆度100°X100°

Components 单元配置低⾳4x4

Connections 连接⽅式夹线

Suspension Point 吊挂点

Enclosure Material 箱体材质12mm多层夹板

Surface treatment 表⾯处理 ⽔性点漆

Dimensions( H x W x D)箱体尺⼨ 550*125*145mm

Weight净重5kg
