System type 系统类型 ⼋单元⼀路⾳箱

Frequency response(-5 dB standard) 频率响应   60Hz-18kHz

Power handling capacity (RMS/peak 10 ms) 功率  280W/500W

Nominal impedance 标称阻抗  4Ω

Sensitivity(1M/W) 灵敏度  99dB

Max SPL 最⼤声压级 115dB

Nominal dispersion angle(h x v) 覆射⻆度  100°X100°

Components 单元配置  低⾳8x4.5 ″

Connections 连接⽅式  夹线

Suspension Point 吊挂点  4个M8螺丝吊挂点

Enclosure Material 箱体材质 12mm多层夹板

Surface treatment 表⾯处理  ⽔性点漆

Dimensions( H x W x D)箱体尺⼨ 1050x125x145mm

Weight净重  9.5kg
